Schneider EVlink Pro DC 180kW

$0.00

Charging Capacity: 180 kW (scalable from 120 kW; 6 × 30 kW power modules)

Outlet Port: 2 (Dual, simultaneous with dynamic energy allocation)

Connector: CCS2 + CCS2 (or CCS2 + CHAdeMO variant)

Input Voltage: 380–415 VAC ±10%, 3-Phase + N + PE

Input Frequency: 50 / 60 Hz

Compatibility: All EVs (incl. 800 V architecture vehicles)

Warranty: 24 months (extended up to 5 years available)

Charging Capacity: 180 kW (scalable from 120 kW; 6 × 30 kW power modules)

Outlet Port: 2 (Dual, simultaneous with dynamic energy allocation)

Connector: CCS2 + CCS2 (or CCS2 + CHAdeMO variant)

Input Voltage: 380–415 VAC ±10%, 3-Phase + N + PE

Input Frequency: 50 / 60 Hz

Compatibility: All EVs (incl. 800 V architecture vehicles)

Warranty: 24 months (extended up to 5 years available)

Schneider Electric High-Power DC Fast Charger

The Schneider EVlink Pro DC 180kW is a premium DC ultra-fast charging station for buildings, depots and fleets. Scalable from 120kW to 180kW with dual CCS2 connectors, it delivers 80% charge in around 20 minutes, features C4M corrosion-protected stainless steel housing and integrates with EcoStruxure EV Charging Expert for intelligent building-wide energy management.

SPECIFICATIONS

•       Output Power: 180kW (scalable from 120kW, 1.5 – 300 A, 150 – 1000 V DC)

•       Dimensions (W x H x D): 1050 x 2202 x 982 mm

•       Weight: 470 kg (without power module); 560 kg (with power module)

•       Mounting: Free-standing floor mounting

•       Charging Mode: Mode 4: 2 x CCS2

•       Output Voltage: 150 – 1000 V DC

•       Output Current: Up to 300 A

•       Connector Type: 2 x SAE CCS Combo 2 (3.6m cable with cable management)

•       Number of Outputs: 2 (dynamic power sharing)

•       Peak Efficiency: 94.5%

•       Input Voltage: 380 – 415 Vac, 3-Phase + N + E, 50/60 Hz

•       Input Current: 291 – 323 A

•       Power Factor: 0.99

•       Enclosure Rating: IP55, IK10 (Screen IK08)

•       Screen Type: 10-inch LCD Touchscreen

•       Status Indication: LCD / LED / Web server

•       Connectivity: 4G, WLAN, Wi-Fi, Ethernet (TCP/IP)

•       Communication Protocols: OCPP 1.6, ISO 15118, DIN 70121

•       User Authentication: RFID (ISO/IEC 14443 A/B), NFC, AutoCharge

•       Enclosure Material: Stainless steel 304 with C4M corrosion protection

•       Cooling: Forced air

•       Operating Temperature: -30°C to +50°C (no derating up to 50°C)

•       Certification: IEC 61851-1 ed.3, IEC 61851-23, IEC 62196, ISO 15118, RCM

•       Warranty: 24 months (extended plans up to 5 years available)
