Delta DC City EV Charger 150kW / 200kW

$0.00

  • Charging Capacity: 150 kW

  • Outlet Port: 2 DC (dual CCS2, simultaneous with dynamic power sharing)

  • Connector: CCS2 + CCS2 (CHAdeMO optional variant)

  • Cable Length: 4 m (standard), 7.5 m (optional)

  • Input Voltage: 380–415 VAC, 3-Phase + N + PE

  • Input Frequency: 50–60 Hz

  • Output Voltage: Up to 1000 V DC

  • Output Current: Up to 200 A per outlet (adaptive)

  • Compatibility: All EVs

  • Warranty: 24 months (extended plans available)

  • Charging Capacity: 150 kW

  • Outlet Port: 2 DC (dual CCS2, simultaneous with dynamic power sharing)

  • Connector: CCS2 + CCS2 (CHAdeMO optional variant)

  • Cable Length: 4 m (standard), 7.5 m (optional)

  • Input Voltage: 380–415 VAC, 3-Phase + N + PE

  • Input Frequency: 50–60 Hz

  • Output Voltage: Up to 1000 V DC

  • Output Current: Up to 200 A per outlet (adaptive)

  • Compatibility: All EVs

  • Warranty: 24 months (extended plans available)

Delta DC City Charger 150 kW / 200kW

Delta City Charger 200kW provides high-efficiency charging service for EV charging stations. With dual outputs and dynamic load distribution, it can serve 2 EVs simultaneously, which boosts the turnover at the charging station. Its industry-leading ≥ 96 % efficiency performance saves energy significantly. It is also compatible with OCPP, allowing backend integration, such as user identification, remote monitoring and control.

Flexible Use Cases:

•    Highway Charging Corridors – High-power top-ups for long-distance travel

•    Service Stations – Forecourt DC fast charging with backend integration

•    Commercial Fleets – Rapid turnaround for medium-duty fleets

•    Public Destination Hubs – High-throughput charging for hotels, shopping and travel hubs

SPECIFICATIONS

  • Dimensions (W x H x D): 850 × 1800 × 680 mm

  • Weight: 400 kg (150kW), 420 kg (200kW)

  • Screen Type: 7 inch integrated touch LCD panel

  • Mounting: Wall-mount or stand-based (indoor / outdoor rated)

  • Peak Efficiency: 94% at nominal output

  • Power Factor: 0.99 at nominal output

  • Operating Temperature: -25°C to +50°C

  • Weather Proofing: IP55

  • Impact Resistance: IK10

  • Connectivity: Ethernet, Cellular, WLAN

  • Status Indication: LED

  • Protocols: Backend system integration with OCPP 1.6

  • Emergency Stop Button — yes, included

  • Load Management — compatible/supported

  • Function Access Control — yes (covers RFID access)
