Delta DC City Charger 100kW

$0.00

Charging Capacity: 100 kW

Outlet Port: 2 DC + optional AC (simultaneous 50 / 50 kW split)

Connector: CCS2, CHAdeMO, Type 2 AC Socket (configurable)

4 m standard (7.5 m optional)

Input Voltage: 380–415 VAC, 3-Phase + N + PE

Input Frequency: 50–60 Hz

Compatibility: All EVs

Warranty: 24 months (extended plans available)

Charging Capacity: 100 kW

Outlet Port: 2 DC + optional AC (simultaneous 50 / 50 kW split)

Connector: CCS2, CHAdeMO, Type 2 AC Socket (configurable)

4 m standard (7.5 m optional)

Input Voltage: 380–415 VAC, 3-Phase + N + PE

Input Frequency: 50–60 Hz

Compatibility: All EVs

Warranty: 24 months (extended plans available)

Delta DC City Charger 100 kW

With 94% power efficiency, dynamic load distribution and multiple connector options, the DC City Charger 100 kW is a versatile and viable DC fast-charging solution for public charging stations, parking lots, shopping malls, commercial offices, hotels and fleets. Its modular design makes power-module replacement easy and keeps the charger operating even if a single module fails.

Flexible Use Cases:

•    Highway Service Areas – Fast top-ups for long-distance EV drivers

•    Service Stations – High-turnover forecourts with mixed vehicle requirements

•    Shopping Malls – Customer dwell-time charging with backend billing

•    Fleet Depots – Mixed light/medium-duty fleet charging at scale

SPECIFICATIONS

•       Dimensions (W x H x D): 800 x 1500 x 590 mm

•       Weight: 350 kg (including 4m charging connectors)

•       Mounting: Free-standing floor mounting

•       Charging Mode: Mode 4: CCS2 + CCS2 or CCS2 + CHAdeMO (+ optional AC Type 2 socket)

•       Output Voltage: 50 – 1000 V DC

•       Output Current: 200 A max. DC; 32 A max. AC

•       Connector Type: 2 x CCS2 (or CCS2 + CHAdeMO), optional AC Type 2 socket

•       Peak Efficiency: 94%

•       Power Factor: 0.99 at nominal output

•       Enclosure Rating: IP55, IK10

•       Screen Type: 7-inch LCD Touchscreen

•       Status Indication: LED / LCD / Mobile App

•       Connectivity: Ethernet, Cellular, WLAN, Bluetooth

•       Screen Type: 7-inch LCD Touchscreen

Bluetooth

•       Communication Protocols: OCPP 1.6J (upgradable to 2.0)

•       User Authentication: RFID (ISO/IEC 14443 A/B Mifare), Credit Card, ISO 15118

•       Cable Length: 4 m standard (7.5 m optional)

•       Cooling: Forced air

•       Operating Temperature: -30°C to +50°C (derating +50°C to +60°C)

•       Certification: CE, RCM
