StarCharge Venus DC Charger 30kW

$0.00

  • Charging Capacity: 30 kW max (V3 also available in 20 kW)

  • Outlet Port: Single

  • Connector: CCS2

  • Cable Length: 5 m

  • Output Voltage: 150–1000 V DC

  • Output Current: 100 A max (30 kW) / 80 A max (20 kW V3 only)

  • Compatibility: Compatible with all CCS2 EVs

  • Warranty: 24 months (extendable depending on supplier agreement)

  • Charging Capacity: 30 kW max (V3 also available in 20 kW)

  • Outlet Port: Single

  • Connector: CCS2

  • Cable Length: 5 m

  • Output Voltage: 150–1000 V DC

  • Output Current: 100 A max (30 kW) / 80 A max (20 kW V3 only)

  • Compatibility: Compatible with all CCS2 EVs

  • Warranty: 24 months (extendable depending on supplier agreement)

The StarCharge Venus is a compact, wall- or pole-mounted DC fast charger delivering 30kW of output with 95% efficiency. Its user-friendly 7-inch touchscreen, robust IP55/IK10 enclosure and OCPP 1.6J connectivity make it the ideal solution for fleet depots, workplaces and destination charging in space-sensitive sites.
Flexible Use Cases:

•       Workplaces & Business Parks – Faster charging for employees and fleet vehicles

•       Retail & Hospitality – Destination charging for guests and customers

•       Fleet Depots – Cost-effective DC charging for small to medium fleets

•       Apartment & Strata – Shared DC charging in space-constrained car parks

SPECIFICATIONS

  • Operating Temperature: -30°C to +50°C

  • Weather Proofing: IP55

  • Impact Resistance: IK10 (screen is IK08)

  • Connectivity: 4G, Wi-Fi, Ethernet

  • Status Indication: 7-inch touchscreen / backend platform

  • Protocols: OCPP 1.6J (V3 also notes OCPP 2.0.1 ongoing)

  • User Authentication: RFID card, App, optional credit card (V2)

  • Emergency Stop Button: Yes

  • Load Management: supported

  • Power Factor: ≥ 0.99 @ full load

•     Dimensions: Venus V2: 680 W × 440 H × 280 D mm,

‍ ‍Venus V3: 700 W × 500 H × 257 D mm

  • Weight: Venus V2: Approx. 35 kg (excluding power modules)

    Venus V3: Approx. 77 kg (including power modules)

  • Screen Type: 7-inch touchscreen

  • Screen Capability: Charging operation interface and charging status monitoring

  • Advertising & Revenue: Backend integration via OCPP for commercial charging management and payment integration

  • Mounting: Wall-mounted or pole-mounted (optional pole)
